DAS ACTION-S18A[PAIR]
About DAS ACTION-S18A[PAIR]
ACTION-S18A is a high-power active subwoofer system that incorporates a 1500 Wpeak amplifier and single 18FW4 speaker with a 3” coil and 20 mm winding depth, double layer and sandwich to boost system power, as well as a new forced convection circuit that that works to reduce the effects of voice coil heating.
As part of our company culture, all our systems are developed under a single philosophy: to deliver the highest possible quality in terms of both materials and overall system design. In the ACTION-500 series we use the same birch plywood as our touring systems for a tight, natural warm sound found nowhere else on the market
erformance | |
Frequency Range (-10 dB) | 35 Hz -125 Hz (variable LPF) |
Maximum Peak SPL at 1 m | 134 dB |
Electronics and Connectors | |
Nominal Amplifier Power (continuous) | 750 W |
Nominal Amplifier Power (peak) | 1500 W |
Input Type | Balanced |
Input Impeadance | 20 kohms |
Input Sensitivity | 1.95 V (+8 dBu) |
Audio Signal Input Connector | 2 x Female XLR |
Audio Signal Loop Thru Connector | 1 x Male XLR |
Control | DAScontrol™ |
Current Draw 230 V / 115 V | 1.4 A/2.8 A |
Net Weight | 42,5 kg ( 93,7 lb ) |
