PIONEER PLX 1000K
About PIONEER PLX 1000K
About trademarks and registered
trademarks
! Pioneer DJ is a trademark of PIONEER CORPORATION and is used
under license.
The names of companies and products mentioned herein are the trade-
marks of their respective owners.
Specifications
Power requirements ........AC 110 V to 120 V or 220 V to 240 V, 50 Hz/60 Hz
Power consumption................................................................................. 9 W
Main unit weight ...................................................................14.6 kg (32.2 lb)
Max. dimensions ........................4 53 mm (W) × 159 mm (H) × 353 mm (D)
(17.8 in. (W) × 6.3 in. (H) × 13.9 in. (D))
Tolerable operating temperature ......... +5 °C to +35 °C (+41 °F to +95 °F)
Tolerable operating humidity ...................... 5 % to 85 % (no condensation)
Turntable part
Drive method ..............................................................Servo type direct drive
Motor ............................................................... 3-phase brushless DC motor
Braking system ................................................................... Electronic brake
Rotation speed ................................................................ 33 1/3 rpm, 45 rpm
Rotation speed adjustment range ............................. ±8 %, ±16 %, ±50 %
Wow and flutter ............................................0.1 % or less WRMS (JIS WTD)
S/N ratio....................................................................................70 dB (DIN-B)
Turntable.................................... Aluminum die-casting Diameter: 332 mm
Starting torque ................................................................ 4.5 kg·cm or more
Start time ............................................................0.3 seconds (at 33 1/3 rpm)
Tone arm part
Arm type .................................................. Universal type S-shape tone arm,
gimbal-supported type bearing structure, static balance type
Effective length.................................................................................. 230 mm
Overhang ............................................................................................. 15 mm
Tracking error .................................................................................. Within 3°
Arm height adjustment range .............................................................. 6 mm
Stylus pressure variable range .............................0 g to 4.0 g (1 scale 0.1 g)
Proper cartridge weight ..............................................................2.5 g to 12 g
* Cartridge weight includes the mounting screws and nuts.
When shell weight is used.........................................................2.5 g to 5.5 g
When only balance weight is used ............................................... 5 g to 9 g
When sub weight is used ...........................................................8.5 g to 12 g
— The specifications and design of this product are subject to
