PROEL V12 PRO-DSP [PAIR]

About PROEL V12 PRO-DSP [PAIR]

V12PRO

2-way active speaker with DSP

The V PRO cabinets, expression of the most advanced Italian design, include a super-comfortable luggage-style top handle for an effortless portability. The slanted shape allows the speakers to be laid on their side and used also as stage monitors.

Specifications:

• System type: 2 way vented enclosure
• High Frequency Device: 1’’ neodymium compression driver
• Low Frequency Device: 12” woofer with 2.5″ VC
• Angular Coverage: 90° H x 60° V
• Total peak power: 600 W
• HF Amplifier Cont. Power: 50 W Class AB
• LF Amplifier Cont. Power: 250 W Class D
• Power Supply type: SMPS
• Frequency Response: 50 Hz – 20 kHz
• Processing: DSP
• Preset: MUSIC, LIVE, DJ, MONITOR, SPEECH
• Max SPL at 1mt (peak): 124 dB SPL
• Crossover Frequency: 2000 Hz
• Input Impedance: 30 kohm balanced / 15 kohm unbalanced
• Input Sensitivity: LINE: +4 dBu / MIC: -30 dBu
• Controls: MIC/LINE, DSP VOICING, LEVEL
• Connectors: MIC/LINE: Combo XLR F / JACK, LINK: XLR M, WIRELESS MIC (U 24H or U 24B)
• Power Supply: 220 240 V~ or 100 120 V~ 50/60 Hz with voltage selector
• Rated Consumption: 300 W
• Construction: Polypropylene
• Cabinet Colour: Black
• Flying System: 4 x M10 top/bottom
• Handles: 1 x top
• Mounting Pole: 1 x bottom
• Monitor taper: 44°
• Weight: 12.8 kg (28.2 lb)
• Dimensions (W x H x D): 380 x 600 x 328 mm
